Пропорционални усмерени вентил 4ВРА

Type 4WRA directional control valves are direct-operated via proportional solenoids. They are widely used in various industrial hydraulic environments that require direction and flow control. Thanks to two long-term collaborations, Huade® proportional directional valves can match the same products offered by Rexroth in performance. The price of this product is relatively lower.

Product parameter of Proportional Directional Valve 4WRA

Product Feature And Application of Proportional Directional Valve 4WRA

Карактеристике:

▶ Direct actuated proportional valve for controlling the direction and volume flow of a hydraulic fluid

▶ за монтажу субплината

▶ За контролу отворене петље и смера и протока хидрауличне течности

▶ Спринг Цонтратед Цонтрол калем

▶ Low pressure drop across the control lands

▶ Both valve and electronic control from one supplier

Примена:

Врста 4ВРА Управљачки вентили се користе за контролу правца и количине протока.

Section and symbol of Proportional Directional Valve 4WRA

Directional control valves type 4WRA consist basically of the housing (1), the control spool (3),one or two return springs (2),and in addition one or two proportional solenoids (5).

Type 4WRA 6......10B/..... and 4WRA 10......10B/.....(3-position valve)

If the solenoids are not activated the control spool (3) is maintained in the neutral position by means of the return springs (2). Actuation of the control spool (3) is directly via the proportional solenoid (5). If, for instance, solenoid ‘A' is energized, it will push the control spool (3) to the right in proportion to the electrical signal. Connections are then made from P to B and A to T.

In this way,the control spool(3)causes the V-shaped grooves to open progressively to flow.When the proportional solenoid (5) is de-energised,the control spool(3) is returned to the center position by the return spring(2).

Structure of Proportional Directional Valve 4WRA

Type 4WRA ...A...10B and 4WRA ...B...10B (2-position valve)

The function of this valve is the same as that for valve type 4WRA.But it's 2-position directional valve with only one

пропорционални соленоид

Тип 4Вра усваја монтажу подлоге, опружни центар и пад ниског притиска преко контролних земљишта.

Често се користе у машини, лаганој индустрији, металургији, руднику, свемирском лету и другим пољима.

Structure of Proportional Directional Valve 4WRA...A... and 4WRA...B...

Симбол пропорционалне усмерене вентил 4ВРА
